Options
111
B
Optional paper tray B
Order Number: LT-100CL
An optional lower tray can be installed, and it
can hold up to 500 sheets of 20 lb (80 g/m
2
)
paper.
When an optional tray is installed, the
machine can hold up to 800 sheets of plain
paper.
Installing the optional paper
tray B
WARNING
This machine is heavy. To prevent injuries
use at least two people to lift the machine.
Be careful not to pinch your fingers when
you set the machine down.
a Turn off the power switch. Unplug the
telephone line cord and interface cable,
and then unplug the power cord from the
AC outlet.
b Using two people, lift the machine
carefully and place it onto the optional
lower tray unit, so that the alignment
pins of the lower tray unit are inserted
into the guide holes on the bottom of the
machine as shown.
c Plug the machine’s power cord back into
the AC power outlet first, and reconnect
all cables and telephone line cord. Turn
on the machine’s power switch.
d To set the paper size for the lower tray,
press Menu, 1, 3, 3. Press a or b to
choose A4, Letter, Legal,
Executive, A5, B5, B6 or Folio.
Press OK, and then press Stop/Exit.
