Loading paper and documents
19
2
Loading envelopes or other media in
the multi-purpose tray (MP tray) 2
Use the MP tray when printing envelopes,
labels, and thick paper.
Before loading, press the corners and sides
of the envelopes to make them as flat as
possible.
a Unfold the output paper tray support
flap (1).
b Open the MP tray and lower it gently.
c Pull out the MP tray support flap (1).
d Put the envelopes (up to 3) or media in
the MP tray with the top edge first and
the print side face up.
1
1
